前言

Wireguard 有两种模式，一直是内核态，一种是用户态。可以通过 modprobe wireguard 检查内核是否支持 Wireguard。如果该命令成功退出并且没有打印错误，则内核模块可用。如果 wireguard 内核模块不可用，可以切换到像 boringtun 这样的用户态实现。

这里以内核态为例。

准备工作

安装 Wireguard

sudo yum install elrepo-release epel-release -y
sudo yum update -y
sudo yum install kmod-wireguard wireguard-tools -y
sudo yum copr enable jdoss/wireguard
sudo yum update -v
sudo yum install wireguard-dkms -y

启用 Wireguard 内核模块
1

sudo modprobe wireguard

自动加载 iptable_raw

1 2	sudo modprobe iptable_raw sudo echo "iptable_raw" \| sudo tee /etc/modules-load.d/iptable_raw.conf

Docker Compose 文件

version: "3"

services:
  wireguard:
    image: linuxserver/wireguard:latest
    container_name: wireguard
    environment:


      - TZ=Asia/Shangai
      - SERVERURL=vpn.example.com
      - SERVERPORT=51820

      - PEERDNS=auto

      - ALLOWEDIPS=192.168.6.0/24
      - PERSISTENTKEEPALIVE_PEERS=25
      - LOG_CONFS=true
    cap_add:
      - NET_ADMIN
      - SYS_MODULE
    volumes:
      - ./config:/config
    sysctls:
      - net.ipv4.conf.all.src_valid_mark=1
    ports:

      - "5000:5000"

      - "51820:51820/udp"

  wireguard-ui:
    image: ngoduykhanh/wireguard-ui:latest
    container_name: wireguard-ui
    depends_on:
      - wireguard
    cap_add:
      - NET_ADMIN

    network_mode: service:wireguard
    environment:
      - SENDGRID_API_KEYc
      - EMAIL_FROM_ADDRESS
      - EMAIL_FROM_NAME
      - SESSION_SECRET
      - WGUI_USERNAME=admin
      - WGUI_PASSWORD=password
      - WG_CONF_TEMPLATE
      - WGUI_MANAGE_START=true
      - WGUI_MANAGE_RESTART=true
    logging:
      driver: json-file
      options:
        max-size: 50m
    volumes:
      - ./db:/app/db
      - ./config:/etc/wireguard

需要修改的参数 SERVERURL,WGUI_USERNAME,WGUI_PASSWORD
